Product description:
JYPU series inverter/charger is combination of an pure sine inverter, battery charger , Auto transfer switch into one complete system. When household AC power is disconnected, the inverter/charger convert DC battery power into AC electricity. When AC power is avaliable, it recharges the battery.JYPU inverter/charger are available in different sizes and power ranges to run various of applications.
Application For:
1. Industrial equipment: solar energy system, solar street light system, etc.
2. Travel set equipment: vehicles, ambulances, RV, boats,traffic lights, etc.
3. Office equipment: computers, printers, scanners, digital cameras, etc.
4. Household electrical equipment: electric fans, vacuum cleaners, air conditioning, lighting,microwave, refrigerators etc.
5. Power tools: Pumps,Saws, drills, punching machines, air compressors, etc.

Product features:
·Pure sine wave output (THD＜3%)
·Built-in 3-stages battery charger,allow to run loads while charging.
·Automatically Switch with a Ultra-fast switching time.
·Soft-start technology.
·High efficiency-converts the battery’s available power
·100% sufficient power.
·Aluminum shell with good heat dissipation and strong shock resistance.
·Optional Crocodile clip and cigar lighters , easy to connect batteries or vehicles’ batteries.
·USB charging port: 5V , ideally qualified for powering your phone,laptop,etc.
·LED indicators for power and protections.
·Switch-mode design, easy to use.
·Intelligent fan for cooling,long use life
·OEM and ODM are available, the color of shell can be customized.
·Optional remote control and LED display for 500W - 3000W inverter/charger.
Protection Functions:
3-Stages charging protection
Over load protection
Over temperature protection
Over voltage protection
Low voltage protection
Short circuit protection
Revers polarity protection
Technical parameter:
Model JYPU-2K-1 JYPU-2K-1 JYPU-2K-2 JYPU-2K-2
Rated power 2000W
Peak power 4000W
Input voltage DC12V DC24V DC12V DC24V
Output voltage 100VAC or 110VAC or 120VAC±5% 220VAC or 230VAC or 240VAC±5%
Unload current less than 1.1A 0.7A 1.1A 0.7A
Output frequency 50Hz±0.5Hz or 60Hz±0.5Hz
Output waveform Pure Sine Wave
Waveform distortion THD＜3%(Linear load)
USB port 5V 1A
Max.efficiency 90%
Input current 15A
Input voltage range 10-15.5V 20-31V 10-15.5V 20-31V
Low voltage alarm 10.5±0.5V 21±0.5V 10.5±0.5V 21±0.5V
Low voltage protection 10±0.5V 20±0.5V 10±0.5V 20±0.5V
Over voltage protection 15.5±0.5V 31±0.5V 15.5±0.5V 31±0.5V
Low voltage recover 13±0.5V 24±0.5V 13±0.5V 24±0.5V
Over voltage recover 14.8V±0.5V 29.5V±0.5V 14.8V±0.5V 29.5V±0.5V
Protection function Low voltage Alarm at first, voltage continously reduce. LED Red light on & shut sown.
Over voltage LED Red light on, shut down
Over load LED Red light on, shut down
Over temperature Alarm at first, tempurature continously rise.LED Red light on & shut sown
Short circuit LED Red light on
Input reverse polarity Fuse burn-out
Output Current 15A 10A 15A 10A
Bulk charge 15A 10A 15A 10A
Absorption 14.6VDC 28.8VDC 14.6VDC 28.8VDC
Float Charging Voltage 13.8VDC 27.6VDC 13.8VDC 27.6VDC
AC Input voltage range 190~260VAC 90-135VAC 190~260VAC 90-135VAC
Working temperature -10°- +50°
Storage temperature -30°- +70°
Dimension(mm) 396x180x128mm
Packing(mm) 400x245x200mm
Net./gross weight(g) 5552/6857g
QTY/Ctn 4 Pcs
Meas./Ctn(mm) 500x400x415mm
Gross weight/Ctn(g) 27410g
Warranty 1 years
Configuration Standard
Cooling method Intelligent air cooling
Note: Our products update constantly.The technical parameter is for reference only.Please refer to our real product.
