Introduction

I-P-Wiser 2 series adopted with auto cool, high conversion efficiency, low power consumption and LCD display. It features an efficient MPPT control algorithm. Added the output function(USB 5V 3A). For the mppt controller can be widely used in off-grid solar system,

Communication base station solar system, household solar systems, street light solar systems, field monitoring and other fields.

Features:

1、 High efficiency MPPT control algorithm, MPPT efficiency ≥99.5%, whole Machine conversion efficiency upto 98%;

2、 Charge mode: three stages (fast charge, constant charge, floating charge). It prolongs service life of the batteries.

3、Discharge mode: ON/OFF mode, Dual time control mode, PV& Time control mode, PV voltage control mode.

4、 Recommended battery types: Flooded, Sealed lead acid, Gel battery. Other types of the batteries can also be defined.

5、 Most information could be provided by LCD like: system type., PV input voltage, PV input current, day, month, total generating power, battery type, battery voltage, charging current, charging power, discharge current, discharge power and so on.

6、 RS485 communication, we can offer communication protocol also, it’s convenient for user’s integration management.

7、 CE, RoHS, FCC certifications approved.. We can help clients to approve other certifications.

8、 2 years warranty. And 3~10 years extended warranty service also can be provided.

Parameters:

MPPT controller Model：		15A	20A	30A	40A	50A
I-P-Wiser2-12V/24V-series
Charge mode	MPPT(maximum power point tracking)
MPPT efficiency	≥99.5%
System type	DC12V/24V system	Automatic Recognition
INPUT CHARACTERISTICS
Max PV input voltage（VOC）	12V/24V system	DC100V		DC150V
High input voltage protection point		DC100V		DC150V
High input voltage recovery point		DC95V		DC145V
Rated PV input power	12V system	200W	260W	390W	520W	650W
	24V system	400W	520W	780W	1040W	1300W
CHARGE CHRECTRESTICS
Charge method	12V/24V system	Three stages charge: constant current(MPPT), constant voltage, floating charge
Rated charge current		15A	20A	30A	40A	50A
Automatic Temperature Compensation		14.2V-（highest temperature-25℃）*0.3
OUTPUT DISCHARGE CHARACTERISTICS
USB (Total for 2 USB output)		DC5V 3A
LOAD output voltage		Based on battery voltage
Rated output current		15A	20A	30A	40A	50A
Output control mode		ON/OFF mode, Dual time control mode, PV&Time control mode, PV voltage control mode
Output control set way		Controller button or PC software
DISPLAY
LCD Display		System type, PV voltage,charge voltage, charging current, charging power, temperature etc.
PC software		RS485
OTHER PARAMETERS
Protection function		Yes (PV Reverse connection, Battery Reverse connection, Over voltage, low voltage, over temperature, over load, Short circuit protection etc.)
Cooling mode		Auto cool
Type of Mechanical Protection		IP30
Measurement DxWxH (mm)		20011066		24315579
Packing DxWxH (mm)		249144105		289189113
N.W. (KG)		0.9		1.8
G.W. (KG)		2		2.5
