Product description

The series for inverter and solar charge discharge controller and battery charger integrated design referred to as inverse control of various filling machine; this is a with high performance, high reliability, load ability, perfect protection, intelligent charging control management function of reverse charging power supply, DC voltage 12V inverter occasions for; can provide reliable modified sine wave power supply for business, household, workstations, home appliances, air conditioning equipment, single-phase power equipment, industrial equipment, power is not more than the product of the rated power. In short it is a powerful, a wide range of intelligent high frequency power control.

Product characteristics

1, Modified sine wave;
2, LED display, you can visually display all the running parameters of the machine;
3, high conversion efficiency, conversion efficiency of 90%, low loss;
4, carrying capacity and anti load capacity;
5, perfect protection function: low pressure, high pressure, high temperature, short circuit, overload, reverse connection protection, etc.;

technical parameter

Inverter Parameters	Model	JYSYM-2000
	Rated power	2000W
	Peak power	4000W
	Input voltage	DC12V	DC24V
	Output voltage	110VAC or 220VAC±5%
	Unload current less than	1.1A	0.7A
	Output frequency	50Hz±0.2Hz or 60Hz±0.2Hz
	Output waveform	Modified Sine Wave
	USB port	5V 1A
	Max.efficiency	90%
	Input current	10A
	Input voltage range	10-15.5V	20-31V
	Low voltage alarm	10.5±0.5V	21±0.5V
	Low voltage protection	10±0.5V	20±0.5V
	Over voltage protection	15.5±0.5V	31±0.5V
	Low voltage recover	12.3±0.5V	24±0.5V
	Over voltage recover	14.8V±0.5V	29.5V±0.5V
	Low voltage	Alarm at first, voltage continously reduce. LED Red light on & shut sown.
	Over voltage	LED Red light on, shut down
	Over load	LED Red light on, shut down
	Over temperature	Alarm at first, tempurature continously rise.LED Red light on & shut sown
	Short circuit	LED Red light on
	Input reverse polarity	Fuse burn-out
Solar Charger Parameters	Battery	12V
	Charging voltage	14.5V±0.3V
	PV Input Current	10-40A
	PV Input Voltage	25V(Max)
	Low Voltage Disconnection	9.5V±0.5V
	Low Voltage Reconnection	12.6V±0.3V
Other Parameters	Working temperature	-10°- +50°
	Storage temperature	-30°- +70°
	Dimension(mm)	300x180x128mm
	Packing(mm)	380x240x195mm
	Net./gross weight(g)	4100/4730g
	QTY/Ctn	4pcs
	Meas./Ctn(mm)	505x405x420mm
	Gross weight/Ctn(g)	18920g
	Warranty	1 years
	Configuration	Standard
	Cooling method	Intelligent air cooling

Note: Our products update constantly.The technical parameter is for reference only.Please refer to our real product.
