Our Products

S1339-150W主图01S1339-150W主图02S1339-150W主图03S1339-150W主图04
PRODUCT FEATURES
Mainly power for household appliances and the base station.
Integrated design for charging household appliances.
High efficient PWM charing technology, intelligent management of battery's charging and discharging.
Compact dimension, low weight, easy to carry.
It can be charged both by solar energy and normal city electricity.
SPECIFICATIONS
Item JYPS1339 JYPS1340
Solar Panel 18V/150W(mono/poly) 18V/300W(mono/poly)
Lead-acid Battery 12V/65AH*1Pcs Deep Cycle Free
Maintenance 		12V/80AH*1Pcs Deep Cycle Free
Maintenance
Inverter Pure Sine Wave 300W/12V
Controller PWM 12V/15A
Output Voltage AC220V
Charging Mode PV Charging, City Electricity Adapter Available
Charging Time 4Hrs by 150W Solar Panel with Efficient
Sunlight 		2.5Hrs by 300W Solar Panel with Efficient
Sunlight
Operating Environment 0-45℃
System Case Size 510*220*222mm
Packing Size 610*1230*300mm
Net Weight 26kg 28KG
Standard Cable Spec. 2.5m㎡*5 & Straight MC4 Connector 1 Pair 2.5m㎡*5 & Straight MC4 Connector 2 Pairs
Load Capacity
Appliance Spec(W) Qty(PCS) Working Hour(h) Power Consumption(W.h)
Mobile Phone 5 2 2 20
LED Bulb 2 3 5 30
Fan 40 1 2 80
TV 100 1 2 200
Washing Mc 240 1 1 240
Total 570
