S201 Solar system

Print This Page

E-Mail To Us: info@jyins.com

Add to Inquiry basket View My Inquiry Basket SEND INQUIRY

PDF File:

PRODUCT FEATURES

Integrated design for powering lighting device,5V digital product,MP3 display and FM radio.
High efficient PWM charging technology, intelligent management of battery's charging and discharging.
Small volume, low weight and easy to carry.
It can be charged by both by solar energy and city electricity.

SPECIFICATIONS

Item	JYPS201		JYPS201A
Solar Panel	18V/10W--25W(Mono/Poly)
Lead-acid Battery	12V/7AH*1Pcs Deep Cycle Free Maintenance
Adapter	No		18V1.5A
Controller	PWM 12V/3A
Output Voltage	DC12V3A, USB5V1A
Charging Mode	PV Charging		PV/City Electricity Charging

Charging Time	7.5H by 10W Solar Panel with Sufficient Sunlight, 6.5h by City Electricity

	3H by 25W Solar Panel with Sufficient Sunlight, 6.5h by City Electricity

Operating Environment	0-45℃
System Case Size	218149164 mm
Packing Size	260190305 mm
Net Weight	3.8 KG
Standard Cable Spec.	5m DC Cable+DC Connector
Battery External Expansion	Unsupportive

Load Capacity

Appliance	Spec(W)	Qty(PCS)	Working Hour(h)	Power Consumption(W.h)
MP3/FM	5	1	2	10
Mobile Phone	5	1	2	10
LED Bulb	2	2	5	20
Fan	10	1	2	20
Total：				60
