PRODUCT FEATURES
Integrated design for charging DC 12V power supply, lighting device ,5V digital products.
High efficient PWM charing technology, intelligent management of battery's charging and discharging.
Compact dimension, low weight, easy to carry.
It can be charged both by solar energy and city electricity.
SPECIFICATIONS
Item JYPS040 JYPS041
Solar Panel 18V/75W （mono/poly） 18V/150W （mono/poly）
Lead-acid Battery 12V/24AH*1Pcs Deep Cycle Free
Maintenance 		12V/33AH*1Pcs Deep Cycle Free
Maintenance
Adapter Optional
Controller PWM 12V/10A
Output Voltage DC12V10A,USB5V1A
City Electricity
Switching Time 		NO
Charging Mode PV Charging
Charging Time 3.5Hrs by 80W Solar Panel with
Sufficent Sunlight 		2.5Hrs by 150W Solar Panel with Sufficent
Sunlight
Operating Environment 0-45℃
System Case Size 330*190*202mm
Packing Size 430*200*270mm
Net Weight 11.5 KG 12.7KG
Standard Cable Spec. 3m DC Cable + DC Connector
Battery External
Expansion 		NO
Load Capacity
Appliance Spec(W) Qty(PCS) Working Hour(h) Power Consumption(W.h)
Mobile Phone 5 1 2 10
LED Bulb 2 2 4 16
Fan 10 1 3 30
TV 25 1 4 100
Refrigerator 20 1 6 120
Total 276
