PRODUCT FEATURES
Integrated design for charging DC 12V power supply, lighting device ,5V digital products.
High efficient PWM charging technology, intelligent management of battery's charging and discharging.
Compact dimension, low weight, easy to carry.
It can be charged both by solar energy and city electricity.
SPECIFICATIONS
Item JYPS031 JYPS031A
Solar Panel 18V/10W--15W（Mono/Poly）
(Lead-acid Battery) 12V/4.5AH*1Pcs Deep Cycle Free Maintenance
Adapter No 18V0.5A
Controller PWM 12V/3A
Output Voltage DC12V3A,USB5V1A
City Electricity
Switching Time 		No
Charging Time 5h by 10W Solar Panel with Sufficient Sunlight,
6.5h by City Electricity
3h by 15W Solar Panel with Sufficient Sunlight,
6.5h by City Electricity
Operating Environment 0-45℃
System Case Size 210*112*123mm
Packing Size 250*150*285mm
Net Weight 2.4 KG
Standard Cable Spec. 5m DC Cable +DC Connector
color:#000000;font-size:12.0pt;font-weight:700;font-style:normal;text-decoration:none;text-align:center;vertical-align:middle;border-left: .5pt solid #000000;border-right: .5pt solid #000000;border-top: .5pt solid #000000;border-bottom: .5pt solid #000000;mso-protection:locked visible;height:14.25pt;width:162.00pt;">155x107x41mm195x134x56mm Net Weight270g530g
Load Capacity
Appliance Spec(W) Qty(PCS) Working Hour(h) Power Consum ption(W.h)
Mobile Phone 5 2 2 20
LED Bulb 2 2 2 8
Fan 10 1 1 10
Total： 38
